E Instruments E4500-N User Manual

49
K000000000EJ 023826A0 100714
CONTEXT KEY FUNCTION
Displays the details of the selecter sensor (see example below).
Returns to the previous screen.
Esc
Example:
9.7.1 Configuration→Diagnostic→Sensors →
Diagnostic
Sensors
S4: NO
2
OK
S3: NO OK
S2: CO OK
S1: O
2
OK
07/08/14
10:00
Diagnostic
Sensors
S4: NO
2
OK
S3: NO OK
S2: CO OK
S1: O
2
OK
07/08/14
10:00
Gas measured
Sensor revision index
Production batch
Sensor serial number
Production date
Calibration date
Sensor Is current
Sensor Ia current
Esc
Diagnostic
Sensors S2
07/08/14
10:00
Is
uA
0.15
Data calibr. 20/01/14
Data prod. 20/01/14
Serial
016944388
Lot 100
Type
A5F rev.8
Gas
CO
Ia
uA
0.05
Diagnostic
Sensors
S4: NO
2
OK
S3: NO OK
S2: CO OK
S1: O
2
OK
07/08/14
10:00
KEY FUNCTION
Activate the context keys shown on the display.
Selects the fuel.
Returns to the previous screen.
Activates the context keys located in the left side of the display.
