E Instruments E4500-N User Manual

53
K000000000EJ 023826A0 100714
9.7.5 Configuration→Diagnostic→On site cal. →
CONTEXT KEY FUNCTION
Once password is entered, gives access to the 'On site calibration' menu.
Shows details for the selected sensor.
Zeroes the timer.
Enters the modification mode for the selected parameter.
Password
On site calibration
07/08/14
10:00
0 0 0 0
OK
OK
KEY FUNCTION
Activate the context keys shown on the display.
Selects line; the selected line is evidenced in red.
In modification sets the value or the desired mode.
Activates the context key located in the left side of the display.
Returns to the previous screen.
When in modify mode cancels the modification just made.
Sets the password.
