Auxiliary relay modes.
Alarm modes.
User manual reference -
Page 19
Beam Tamper Alarm.
In cases where the safety beams have been tampered with, the safety protocols will sll allow the gates to open but will not allow the gates to close.
This safety feature can be turned into a security risk by anyone with ill intenon. The beam tamper alarm feature gives you a ealry warning of any
tampering that may have occured while you were away from the property. If the gates are in the closed posion and the safety beam input is trigger
for longer than 20 seconds, then the auxiliary relay will become acve in this mode. This would usually be connected to a visual warning device such
as a light or to a zone on the household alarm system.
In the case of a light being used, on approach to the entrance the user is alerted to the aempt to compromise their security. Our advice is that the
user not trigger the gates to open, in this situaon, but rather to connue driving to their nearest armed response standby point or to the nearest
police staon. This way they can ask for an escort onto the property.
Beam tamper alarm mode is available in all modes of operaon so long as a set of safety beams is installed.
Acon Response
Safety beam equipment
tampered with while
gates are in the closed
posion.
Auxiliary relay
remains in
standby status.
20 seconds aer safety
beam equipment has
been tampered with.
Auxiliary relay
acvates.
Safety beam equipment
returned to normal
funconing status.
Auxiliary relay
returns to
standby.
Gate closed.
OFF
Com N/O
N/C
O
0
20 sec.
ON
Com N/O
N/C
On
OFF
Com N/O
N/C
O
Gate forced open alarm.
In a case where the gate is physically lied o its track and forced open, the auxiliary relay will immediately acvate. The auxiliary relay will only reset
when the gate is returned to normal secured condion in the closed posion.
Acon Response
Gate secured in the
closed posion.
Standing by.
Auxiliary relay
remains in
standby status.
Aempt to li gate o
track and force open.
Auxiliary relay
acvates.
Gate resecured in
the closed posion.
Standing by.
Auxiliary relay
returns to
standby.
OFF
Com N/O
N/C
O
ON
Com N/O
N/C
On
OFF
Com N/O
N/C
O
