E.T. Systems Drive 300 - Positive Close Mode Functionality

45
User manual reference -
Page 20
Posive close mode.
Advanced features
With posive close mode acvated, the gate will surge onto the closed stopper aer seeing the closed limit.
This feature is useful when installing an electric lock or when trying to ensure an electric fencing gate contact always closes when the gate is in the
closed posion.
Acon Response
Momentary BT trigger.
Gate begins
opening.
No buzzer tones.
At full open posion. Gate stops. No buzzer tones.
Momentary BT trigger.
Gate begins
closing.
No buzzer tones.
Momentary BT trigger. Gate stops. No buzzer tones.
Momentary BT trigger.
Gate begins
opening.
No buzzer tones.
Momentary BT trigger. Gate stops. No buzzer tones.
Momentary BT trigger.
Gate begins
closing.
No buzzer tones.
At full closed posion.
Closed limit
acvates.
No buzzer tones.
When the closed limit
acvates.
Gate connues
to surges onto
the mechanical
closed stopper.
No buzzer tone.
STOP
STOP
