E.T. Systems Drive 300 - Duty Cycle Calculation and Motor Positioning; Gate Motor Installation Location Criteria

7
Duty Cycle.
The Formula used to determine duty cycle is:
Run me
x 100 = Duty cycle
Run me + rest me
Working example 1: (Low duty cycle)
Run me: 12 seconds.
Rest me: 36 seconds.
12 ÷ 48 x 100 = 25
Thus the duty cycle in example 1 is said to be 25%
Working example 2: (High duty cycle)
Run me: 12 seconds.
Rest me: 1 second.
12 ÷ 13 x 100 = 92.3
Thus the duty cycle in example 2 is said to be 92.3%
The above examples do not factor in resistance and gate mass. These two elements contribute greatly to the amount of heat generated in your gate
automaon system.
Below are the maximum allowed duty cycles based on the gate mass and rolling resistance for the ET motor models. These are calculated to conform
to the standards set out in the SANS 60335-95-1:2011 safety code.
Duty cycle capabilies guideline of the ET Drive series motor models:
Model Gate Mass Starng resistance Rolling resistance Max Duty Cycle
Drive 300 ≤ 300kg ≤ 30kgf ≤ 24 kgf 25%
Where to posion the gate motor.
Liquid ingress:
The ET Drive series motor models all carry an ingress protecon rang of IPX4. This means they are protected from splashing water. They are not
water ght as there are sensive electronic and electrical circuits that require uninhibited airow to remain cool and dry.
When deciding on an installaon posion, be aware of water collecon points around and near the desired mounng posion of the motor unit. If
the water does not ow away quickly enough, it can seep into the system and cause expensive and possibly hazardous damage. Always install the unit
higher than the highest level that any water owing past the motor unit can reach.
Physical protecon:
Whenever possible, always install the gate motor on the opposite side of the gate’s guide/emergency post, to the driveway itself. This way it is out of
the path of the motor vehicles as they pass through the entrance/exit.
