E.T. Systems Drive 300 - Component Identification and Unit Dimensions; Operator Unit Physical Dimensions

5
1
2
3
4
5
6
7
7
8
9
10
12
11
13
14
15
16
17
18
Component idencaon and descripons.
Diagram
number
Descripon
Diagram
number
Descripon
1 Control card 10 Baseplate
2 Dashboard 11 220V connector
3 Plug-in terminal connectors 12 Manual release
4 Manual release monitoring reed switch 13 Manual release lock
5 Baery 14 Electric motor
6 Transformer housing 15 Electric motor brush ports
7 Mounng bolts 16 Revoluon counter ring magnet
8 Gearbox 17 Ends of travel limits, reed switch
9 Cable inlets 18 Output drive pinion
260213
15
91
258
Operator dimensions.
