CHECKING THE STEERING HEAD
CHK
ADJ
4. Remove
• Front cap
a. Remove the upper ring nut .
b. Loosen the lower ring nut .
CHECKING THE STEERING HEAD
1. Stand the scooter on a level surface.
WARNING
• Please support by main stand.
2. Use a support put in the buttom of vehicle and
raise the front wheel.
• Meter
• Side cover (L)
• Headlight
• Side cover (R)
5. Adjust
• Steering head
Securely support the scooter so that there
is no danger of it falling over.
T
R
.
.
3. Check
• steering shaft bushings and bearings
Grasp the bottom of the front fork legs and
gently rock the front fork.
Binding/looseness
ĺ
adjust the steering hand.
Refer to “STEERING SYSTEM” in chapter
7.
Refer to "FRONT FORK" in chapter 7.
TIP
TIP
Lower ring nut (initial tightening torque)
35 Nm (3.5 m • kg, 25.3 ft • lb)
3
3-8
c. Use a steering nut wrench and tighten
the lower ring nut .
Install a ring nut wrench on the steering nut wrench
and tighten by verticality and get the tightening
torque.
1
1
2
2
2
2
3
3
