E-TON EV3 E-MO - Installing the Front Fork

T
30 Nm(3.0 m•kg, 21.7 ft•lb)
T
R
.
.
30 Nm(3.0 m•kg, 21.7 ft•lb)
b
b
7-24
FRONT FORK
CHAS
3. Install
• Dust seal
• Circlip
Couple the circlip correctly on the groove of the
outer tube.
4. Check
• Operation of inner tube
8QVPRRWKRSHUDWLRQĺUHSODFH
INSTALLING THE FRONT FORK
Reverse the disassembly procedure. The following
points should be remembered.
1. Install
2. Tighten
• Front fork
• Bolt
• Nut (fork)
• Cap
1
1
1
1
1
2
2
2
3
3
a
TIP
