E-TON EV3 E-MO - Steering System; Headlebar

1
31
1
4
1/1
51
21
1
3
4
2
4
5
7-14
T
R
.
.
45 Nm (4.5 m • kg, 32.5 ft • lb)
STEERING SYSTEM
HEADLEBAR
CHAS
Remove the parts in the order listed.
RemarksQ’tyJob/PartOrder
For installation, reverse the removal pro-
cedure.
Front brake cable
Front cap
Meter side L/ R
Headlight
Meter
Handle lever assembly (L)
Handlebar grip (L)
Handle lever comp (R)
Left / right brake lever
Handlebar
Refer to "MOVING AND INSTALLING
COVER " in cheaper 3.
