LOWER BRACKET
CHAS
1. Remove
REMOVING THE LOWER BRACKET
• Front fender assembly
• Ring nut
• Ball race cover
• Bearing ball
• Ball race outer
• Ball race upper
• Removing the ring nut by the steering nut wrench
.
• Support the front fork safety and firmly, avoid
topple and fall.
• Do not lose the bearing ball inside of the bearing.
2. Remove
• Front fender
Please refer to "FRONT FROK" in cheaper 7.
CHECKING THE LOWER BRACKET
1. Washing the bearing ball with solution.
2. Check
• Bearing ball
3LWWLQJGDPDJHĺUHSODFH
3. Check
• Lower bracket
3LWWLQJEHQGVGDPDJHĺUHSODFH
WARNING
Do not attempt to straighten a bent lower bracket
as this may dangerously weaken the lower
bracket.
TIP
