1
3
1
1
4
1
2
1
5
6
1/1
1
7-2
1
3
4
2
5
6
1
(x4)
T
R
.
.
4Nm(0.4m• kg, 2.9 ft • Ib)
T
R
.
.
80 Nm (8.0 m • kg, 57.9 ft • Ib)
T
R
.
.
4 Nm (0.4 m • kg, 2.9 ft • Ib)
FRONT WHEEL / REAR WHEEL
REAR WHEEL
CHAS
Remove the parts in the order listed.
For installation, reverse the removal pro-
cedure.
RemarksQ’tyJob/PartOrder
Removing the rear wheel
TIP
Place the scooter on a suitable stand so
that the front wheel is elevated.
Rear bottom cover L/R
Rear fender
Rear fender bracket
Rear wheel
Hexagon flange bolt
Rear brake shoe plate
To Next Page
