CHECKING THE SWITCHES
6-4
CHECKING THE SWITCHES
Check each switch for damage or wear, proper
connections, and also for continuity between the
terminals. Refer to “CHECKING SWITCH CON-
TINUITY”.
Damage/wear Repair or replace.
Improperly connected
Properly connect.
Incorrect continuity reading
Replace the
switch.
G/
Y
B/
Y
Turn signal switch
Headlight switch
Horn switch
Front brake switch
Rear brake switch
Main switch
Main fuse
Turn signal fuse
1
2
3
1
2
3
4
5
678
4
5
6
7
8
–+
ELEC
ON
OFF
ON
OFF
Br LG
Br/Y
Y/R
L/Y B/Y B/Y
ON
OFF
L
R
PUSH
LG Y/L B/Y
Br
LG
Br
Br/Y
Y/L
Br/Y
Y/R
B/Y
Y/R
G
/Y
B
/Y
Y/Br
Y/G
Y/Br
Y/Br
Y/G
Y/G
10A30A
