E-TON EV3 E-MO - Replacing the Tail Light Bulb

3-14
WARNING
Since the light bulb gets extremely hot, keep
flammable products and your hands away
from the bulb until it has cooled down.
WARNING
Since the light bulb gets extremely hot, keep
flammable products and your hands away
from the bulb until it has cooled down.
New
TIP
REPLACING THE TAIL LIGHT BULB
• Press the bulb in and counterclockwise
revolving will take it out.
TIP
• Lens.
• Bulb.
TIP
• Press the bulb in and clockwise revloving
will insert into the holder site.
REPLACING THE FRONT/ REAR TURN LIGHTS BULB/
REPLACING TAIL LIGHT BULB
CHK
ADJ
• Lens.
• The turn light holder site.
2. Install
• Bulb.
• Left/ right turn light.
• Make sure the bulb infix to groove .
1. Remove
• Lens .
• Bulb .
2. Replace
• Bulb (burned).
3. Install
• Make sure the bulb infix to groove.
1
1
2
3
3
b
a
2
b
a
