E-TON EV3 E-MO - Chas; Front Wheel; Rear Wheel; Front Wheel

1
FRONT WHEEL / REAR WHEEL
FRONT WHEEL
RemarksQ’tyJob/PartOrder
Removing the front wheel
31
1
4
1
Hexagon flange bolt
52
Front wheel
62
Front brake shoe plate
21
Collar B
71
Collar A
Oil seal
Bearing
1
3
4
5
6
2
5
6
7-1
CHAS
Remove the parts in the order listed.
TIP
Place the scooter on a suitable stand so
that the front wheel is elevated.
For installation, reverse the removal pro-
cedure.
T
R
.
.
35 Nm (3.5 m • kg, 25.3 ft • lb)
7
