LIGHTING SYSTEM
6-8
TROUBLESHOOTING
Check:
1. main fuse
2. battery
3. main switch
TIP
• Before troubleshooting, remove the follo-
wing part(s):
• Troubleshoot with the pocket tester.
Any of the following fail to light: head-
light,
and meter light.
4. headlight switch
5. wiring connections
1. Main fuse
• Check the fuses for continuity.
Refer to “CHECKING THE FUSES” in
chapter 4.
• Is the fuse OK?
YES NO
Replace the fuse.
4. Headlight switch
• Check the headlight switch for continuity.
Refer to “CHECKING THE SWITCHES”.
• Is the headlight switch OK?
5. Wiring
• Check the entire lighting system’s wiring.
Refer to “CIRCUIT DIAGRAM”.
• Is the lighting system’s wiring properly con-
nected and without defects?
The headlight switch is
faulty. Replace the left
handlebar switch.
Properly connect or
repair the lighting
system’s wiring.
Check the condition of
each of the lighting sy-
stem’s circuits. Refer to
“CIRCUIT DIAGRAM”.
YES
NO
YES
NO
2. Battery
• Check the condition of the battery.
Refer to “CHECKING AND CHARGING
THE BATTERY” in chapter 3.
Minimum open-circuit voltage
40.0 V or more at 20°C
• Is the battery OK?
`YES NO
• Clean the battery terminals.
• Recharge or replace the
battery.
3. Main switch
• Check the main switch for continuity.
Refer to “CHECKING THE SWITCHES”.
• Is the main switch OK?
YES NO
Replace the main switch.
–+
ELEC
2.Cap,front
1.Seat
