7-16
STEERING SYSTEM
CHAS
INSTALL THE HANDLEBAR
Reverse the removal procedure for installation and
pay attention the following tips:
1. Clean
• If the connection part of steering touch with
grease, should be clean.
2. Install
• Handlebar
• Securely support the scooter so that there
is no danger of it falling over.
• Install all cables should refer to "CABLE
• Flange bolt
ROUTING" in cheaper 2.
Align the lower handlebar holder with the upper
groove of steering.
• Handle lever assembly (L)
• Handlebar grip (L)
• Handle lever comp (R)
• Left / right brake lever
Lubricate the inside of the throttle grip with a thin
coat of lithium soap base grease and install it
onto the handlebar.
1
1
2
2
a
a
