Eaglemaster E8 - Program controlled additional channel (CH-5); Additional channel (CH-6)

. Control of the CH-4 (Remote latched) - Press the button over 2sec.
Simply press and hold button 3+4 over 2 seconds, the channel will constant output .
To exit by press and hold button 3+4 over 2 seconds, the channel will deactivated.
. Control of the CH-4 (programming time output with sensor off /on) -
Press the button over 2sec.
Simply press and hold button 3+4 over 2 seconds, the channel will constant output
The sensor zones can be turn off or on status , during the channel activated, check Table-2
of NO.8.
for the
pre-programmed period of time or until press the button 3+4 over 2 seconds.
This channel "Orange wire" is a negative pulsed output.
- Program controlled additional channel (CH-5)
The channel can be used for:
(Table-2 of NO.3)
- Armed output (for interlock N/C type)
- Disarmed output (for interlock N/O type)
This CH-5 output for the car with engine start killer feature while active the system.
Armed or disarmed output can be programme by Table-2 of NO.3 . This wire may be wired
to an optional starter kill relay .
This channel "Yellow wire" is a negative pulsed output.
- Additional channel (CH-6)
This CH-6 output for the car with
engine start killer feature as soon as system disarmed. This wire may be wired to an
optional starter kill relay .
If you select this function the stage-by-stage unlocking of driver's then passengers' doors
one after another is automatically carried out with the remote transmitter if you sequentially
press the disarming button. Control of unlocking of the passengers doors by the signal of
one of additional channels (CH4 ) to be programmed respectively.
When you first time press the disarming button 2 the system will enable driver's door
unlocking and when you press the button once again the CH4 will be enabled for
Passengers' doors unlocking.
. Control of the CH-4 (2nd stage door unlock)
2-way LCD display :
To indicate that the
engine blocked.
CH-5/CH-6 activated.
