Eaton i-on16 Installation Guide

Programming i-on16
Page 20
Installer Menu
Important: If the control unit does not comply with EN50131 you must remove any labelling that indicates
compliance.
1 DETECTORS/ DEVICES
Detectors
Add/Del Detectors
Program Zones
Zone 01...16
Name
Type
Attributes
1
Wired Keypads
Edit Keypad
Keypad K1-01...K1-02
Name
Radio Keypads
Add/Del Radio Keypad
Edit Keypads
Radio Kpd 01...02
2
Name
External Sirens
Add/Delete Ext. Siren
Edit external siren
Siren 01...02
Name
2 OUTPUTS
Radio outputs
Add Outputs
Edit Outputs
O/P1...O/P8
Name
Type
Pulsed
Wired outputs
Panel
O/P1...O/P4
Name
Type
Polarity
Pulsed
3 SETTING OPTIONS
Full Set
Name
Exit mode
Settle time
3
Exit time
4
Entry time
Siren Delay
Siren Time
Strobe on Set
Strobe on Unset
Part Set B
Name
Exit Mode
Settle time
3
Exit time
4
Entry time
Alarm Response
Siren Delay
Siren Time
Pt. Set Final Exit
Pt. Set Entry Route
Strobe on Set
Strobe on Unset
Volume
Part C, D
4 SYSTEM OPTIONS
Wired Zone Type
15
User Access
HUA keys active
Quick Set
Quick Omit
User code req’d
2 Way Replies
2 Way Set Instant
Duress Enable
User reset
Zone alarms
5
Zone tampers
System tampers
Confirmation (-UK
version)
Confirmation Mode
DD243
BS8243
Basic
Confirmation time
6
After Entry
6
Entry Keypad Lock
6
Sounder on
Siren on
Unconfirmed reset
6
Confirmed reset
6
HUA Confirm time
7
Tamper as Tamper only
7
Confirmation (-EUR
version)
Sounder on
Siren on
Language
8
Profiles
Restore Defaults
Factory defaults
Installer Name
Installer Code
Keypad text
Remote Needs Entry
Remote Entry PrtSt
RKP Needs Entry
RKP Entry PrtSt
HUA Response
Auto Rearm
5
Panel Loudspeaker
Volume
Entry Alarm Delay
Abort Time
Supervision
Jamming
Force Set
Tamper Omit
CSID Code
Silence Alerts
Mains Fail Delay
Set Date & Time
Panel Tamper Rtn
5 COMMUNICATIONS
10
ARC Reporting
10
Call Mode
Phone book
Account Number
Report Type
Fast Format channels
11
CID/SIA Events
12
Restorals
Burg Comms Rearm
9
21CN FF Ack time
11
Send tamper as burg
12
Dynamic Test Call
13
Static Test Call
14
Unset Comms
Speech Dialler
10
Call Mode
Messages
Phone Book
Triggers
Destinations
Call Acknowledge
SMS
10
Call Mode
Messages
Phone Book
Triggers
PSTN SMS
Protocol
Service Centre Tel
Line Fail Response
10
Line Fail Delay
10
6 TEST
Sirens & Sounders
Wired Keypad
Radio Keypads
Walk Test
Zone Resistances
15
Signal Strengths
Detectors
Radio Keypads
External Sirens
Outputs
Radio Outputs
Wired Outputs
Remotes
User HUAs
Prox Tags
ARC Reporting
10
Speech Dialler
10
7 VIEW LOG
All Events
Mandatory Events
Non-Mandatory Events
8 ABOUT
Panel
Keypads
Comms
Module
1
Appears when zone is given a type other than “Not
Used”.
2
Appears only when device learned in.
3
Appears only if Exit Mode is “Final Door” “Lock Set”
or “Exit Terminate”.
4
Appears only if Exit Mode is “Timed Set” or “Silent
Set”.
5
Appears only when System Options – Confirmation
Mode is “Basic”.
6
Appears only if System Options – Confirmation
Mode is either “DD243” or “BS8243”.
7
Appears only if System Options – Confirmation
Mode is “BS8243”.
8
Appears only in EUR version.
9
Appears only when Report Type=Fast Format AND
System Options – Confirmation Mode is “Basic”.
10
Appears only when i-sd01 fitted.
11
Appears only when Report Type=Fast Format.
12
Appears when Report Type=CID or SIA
13
Appears only when Static Test call disabled.
14
Appears only when Dynamic Test Call disabled.
15
Appears only when KEY-KPZ01 is fitted.
