Eaton i-on16 Installation Guide

i-on16 Technical Specification
Page 23
Monitoring includes
Mains fail, battery low
voltage, battery failure.
Electromagnetic Compatibility
Immunity
Conforms to EN50130-4.
Emissions
Conforms to EN61000-6-
3.
Outputs
O/P 1 - 4
Open collector
transistor, +12VDC
when inactive, 0V when
active. 500mA max.
LS (loudspeaker)
Min impedance 16 Ohm,
current consumption
from 12VAux = 280mA
in alarm.
Fuses
The control unit has a 250mA mains fuse.
Electrical Safety
Conforms to EN60950-1.
Compliance Statements
This product is suitable for use in systems designed
to comply with PD 6662: 2010 at grade 2 and
environmental class II.
This product complies with the requirements of
50131-3 at grade 2 and environmental class II.
This product complies with the requirements of
EN50131-6:2008 at grade 2 and environmental
class II.
When fitted with an I-SD01 this equipment is
compliant with EN 50136-1. It allows the alarm
transmission system to meet the performance
requirements of EN 50131-1:2006 ATS 2 provided
that:
a) It is installed in accordance with the installation
instructions.
b) The connected PSTN is functioning normally.
If the installer selects a non-compliant
configuration then they must remove or adjust
compliance labelling.
Compatible Equipment
HUD
705rEUR-00 Two button HUD (single
channel, top button is disabled)
706rEUR-00 Two button HUD/tilt switch
transmitter
710rEUR-00 Two button HUD
726rEUR-50 Long range hand held HUD
726rEUR-60 Short range hand held HUD
Detectors
713rEUR-00 Pet tolerant PIR
714rEUR-00 PIR Transmitter (Small case)
720rEUR-00 Smoke Detector Transmitter
734rEUR-00/01 CC/FSL Door Contact
Transmitter (white)
734rEUR-05/06 CC/FSL Door Contact
Transmitter (brown)
738rEUR-00/04 Spyder shock sensor
(white/brown)
739rEUR-50 Sentrol glass break detector
DET-RDCS Combined door contact shock
sensor transmitter
xcelr Radio PIR
xcelrpt Pet tolerant radio PIR
xcelw Wired PIR
xcelwpt Pet tolerant wired PIR
Sounders
760ES External Wireless sounder
9040UK-00 Speaker boxed
Setting / Unsetting – Keypads
i-rk01 Radio Keypad
i-kp01 Keypad (with internal prox
reader, but without zones or
external prox reader)
KEY-EP External prox reader for KEY-
KPZ01/KP01
KEY-K01 keypad
KEY-KP01 keypad with internal prox
reader and terminals for
external prox reader
KEY-KPZ01 keypad, with internal prox
reader, two zones, one output
and terminals for external prox
reader
Setting / Unsetting - Fobs
FOB-2W-4B Two-way keyfob
i-fb01 Four button remote control
727rEUR-00 Four button remote control with
encrypted code (HUD function
not compatible with BS8243 or
DD243)
Communicators
i-sd01 PSTN Communication module
with speech dialling
Accessories
703rEUR-00 4-channel (2 zone) transmitter
762rEUR-00 Two Channel Receiver
768rEUR-50 Eight Channel Receiver
770rEUR-00 Wireless Accessory Module
771rEUR-00 Info Module
i-rc01 Relay Card
