6. Technical Specification
Specification
General
Product name
i-on16.
Product Description
16 radio zone
endstation with remote
keypad.
Manufacturer
Eaton’s Security
Business
Environmental
Class II.
Operating
temperature
Tested -10 to +55°C.
Dimensions:
End station
384 x 245 x 94, mm
HxWxD.
i-kp01
115 x 156 x 34, mm HxWxD
KEY-K01/KP01/KPZ01
128 x 128 x 29, mm HxWxD
Weight:
End station
2.1 kg (without stand-by
battery).
i-kp01
0.26 kg
KEY-K01/KP01/KPZ01
0.19 kg
Case material
ABS.
Zones
16 radio.
Remote controls
16.
Hold Up Alarms
16.
Outputs
4 wired.
Internal Clock
±10 minutes over one
year (depending on the
accuracy of the mains
supply frequency).
Log capacity
250 events mandatory,
15 non-mandatory,
stored in flash memory
(requires no support
battery)
Security
Security Grade
Grade 2.
Radio detector
differs
16,777,214 (2
24
-2).
Radio Supervision
Programmable.
Access code
4 digits, all four digits may
be any number 0 to 9,
giving 10,000 differs.
Number of user
codes
16 plus installer
Code blocking
Blocked for 90s after four
incorrect codes in series.
Proximity tag
differs
4,294,967,296 (2
32
)
Radio
Radio Section
Operating frequency
868.6625MHz
Narrowband.
EN 300 220-3.
EN 300 330-2
Telefication
Transmitter range
The range of the
transmitters compatible
with this control unit
depends on the
environment in which they
are installed. As a
guideline, most
transmitters will work up
200m range in free space
conditions.
Communications
Uses plug on modules with proprietary interface
between control unit and module.
Note: Not suitable for a policed system.
I-SD01 Communication Module/PSTN
The I-SD01 module provides connection to the
PSTN. The module allows both speech messaging
and alarm signalling. When fitted to the control unit
speech messages can be configured to be up to
30s long (one 10s home message and four
consecutive alarm messages of 5s each).
The I-SD01 module meets the performance criteria
of D2, M2, S1, I0, T2 and A0 as described in
EN50136-1-1 subject to network conditions.
ATS rating ATS 2 (EN50131-1)
This product can share a PSTN line with other
telephony or fax equipment.
REN 1
Power Supply
This product complies with the requirements of
EN50131-6 Type A power supply at Grade 2 and
environmental class 2.
Mains power supply
230VAC +10%/-15%,
170mA max, 50Hz.
End station psu
13.7VDC, 1.5A max
End station
consumption
145mA.
Communicator
consumption
50mA max
i-kp01 power
requirement:
30mA (normal/idle)
45mA (backlight low)
65mA (backlight high)
KEY-
KPZ01/KP01/K01
35mA backlight OFF,
internal prox reader only.
65mA max backlight ON,
external prox reader
connected
Standby Battery
12V, 7Ah sealed lead
acid.
Standby time:
More than 12 hours.
Max recharge time:.
Less than 72 hours
Battery charge limit
270mA
12V Aux supply (inc
LS)
13.7VDC +0.1/-0.4 @
850mA max.
14V4 supply
14.4V +0.1/-0.2 @
230mA
12V Keypad bus
13.7V =0.1/-0.5 @
400mA max
