Chapter 1—DG1 Series Overview
DG1 Series VFD MN040002EN—March 2014 www.eaton.com 5
DG1 Series Drives—380–500 Volt
Table 4. Type 1/IP21
Table 5. Type 12/IP54
Note
1
FR6 available in 2015.
Frame Size
400V, 50 Hz
kW Rating (CT/I
H
)
400V, 50 Hz
kW Rating (VT/I
L
)
460V, 60 Hz
hp (CT/I
H
)
460V, 60 Hz
hp (VT/I
L
)
Current
A (CT/I
H
)
Current
A (VT/I
L
) Catalog Number
FR1 0.75 1.1 1 1.5 2.2 3.3 DG1-342D2FB-C21C
1.1 1.5 1.5 2 3.3 4.3 DG1-343D3FB-C21C
1.5 2.2 2 3 4.3 5.6 DG1-344D3FB-C21C
2.2 3 3 5 5.6 7.6 DG1-345D6FB-C21C
345—7.69DG1-347D6FB-C21C
4 5.5 — 7.5 9 12 DG1-349D0FB-C21C
FR2 5.5 7.5 7.5 10 12 16 DG1-34012FB-C21C
7.5 11 10151623DG1-34016FB-C21C
11 15 15 20 23 31 DG1-34023FB-C21C
FR315 18.5 20253138DG1-34031FB-C21C
18.5 22 25303846DG1-34038FB-C21C
22 30 30 40 46 61 DG1-34046FB-C21C
FR430 37 40506172DG1-34061FN-C21C
37 45 50 60 72 87 DG1-34072FN-C21C
45 55 60 75 87 105 DG1-34087FN-C21C
FR5 55 75 75 100 105 140 DG1-34105FN-C21C
75 90 100 125 140 170 DG1-34140FN-C21C
90 110 125 150 170 205 DG1-34170FN-C21C
FR6
1
110 132 150 200 205 261 DG1-34205FN-C21C
132 160 200 250 261 310 DG1-34261FN-C21C
Frame Size
400V, 50 Hz
kW Rating (CT/I
H
)
400V, 50 Hz
kW Rating (VT/I
L
)
460V, 60 Hz
hp (CT/I
H
)
460V, 60 Hz
hp (VT/I
L
)
Current
A (CT/I
H
)
Current
A (VT/I
L
) Catalog Number
FR1 0.75 1.1 1 1.5 2.2 3.3 DG1-342D2FB-C54C
1.1 1.5 1.5 2 3.3 4.3 DG1-343D3FB-C54C
1.5 2.2 2 3 4.3 5.6 DG1-344D3FB-C54C
2.2 3 3 5 5.6 7.6 DG1-345D6FB-C54C
345—7.69DG1-347D6FB-C54C
4 5.5 — 7.5 9 12 DG1-349D0FB-C54C
FR2 5.5 7.5 7.5 10 12 16 DG1-34012FB-C54C
7.5 11 10151623DG1-34016FB-C54C
11 15 15 20 23 31 DG1-34023FB-C54C
FR315 18.5 20253138DG1-34031FB-C54C
18.5 22 25303846DG1-34038FB-C54C
22 30 30 40 46 61 DG1-34046FB-C54C
FR430 37 40506172DG1-34061FN-C54C
37 45 50 60 72 87 DG1-34072FN-C54C
45 55 60 75 87 105 DG1-34087FN-C54C
FR5 55 75 75 100 105 140 DG1-34105FN-C54C
75 90 100 125 140 170 DG1-34140FN-C54C
90 110 125 150 170 205 DG1-34170FN-C54C
FR6
1
110 132 150 200 205 261 DG1-34205FN-C54C
132 160 200 250 261 310 DG1-34261FN-C54C
