Eaton PowerXL DG1-323D7FB-C21C - Figure 35. FR3 Dimension Drawing

Appendix C—Dimension Drawings
DG1 Series VFD MN040002EN—March 2014 www.eaton.com 59
Approximate Dimensions in Inches (mm)
Figure 35. FR3 Dimension Drawing
21.97
(558.0)
7.24 (184.0)
7.48 (190.0)
REMOTE RUN FAULT
STOP
BACK
RESET
LOCAL
REMOTE
OK
START
MS NS
DANGER
5 MIN
REMOTE RUN FAULT
STOP
BACK
RESET
LOCAL
REMOTE
OK
START
MS NS
DANGER
5 MIN
A = Air gap around drive
B = Space between two drives or
drive and cabinet
C = Free space above drive
D = Free space below drive
Minimum Dimensions
For Class IP54, dimension A and B = 0
C 7.87
(200.0)
D 3.15 (80.0)
A/B
1.97
(50.0)
13.49
(342.6)
3.83
(97.2)
21.46
(545.0)
4.92
(125.0)
10.44 (265.1)
0.45 (11.3)
0.59 (15.0)
20.41
(518.5)
8.06 (204.6)
4.92
(125.0)
2.77 (70.3)
1.26 (32.0)
3-Ø0.89
(Ø22.5)
1.93
(49.0)
6.23
(158.3)
2.03 (51.5)
1.92 (48.8)
2.19 (55.5)
0.18 (4.5)
4.92
(125.0)
0.35
(Ø9.0)
3-Ø0.14
(Ø35.0)
A/B
1.97
(50.0)
0.71
(Ø18.0)
4.92
(125.0)
0.35
(Ø9.0)
1.26 (32.0)
Type 1/12 ULIP21/IP54 Metric
48.8
63.3
39.0
49.0
158.3
51.5
3-Ø35.0
39.0
3-Ø25.3
55.5
