Eaton PowerXL DG1-323D7FB-C21C - Table 8. Frame 3; Table 9. Frame 4

Chapter 1—DG1 Series Overview
DG1 Series VFD MN040002EN—March 2014 www.eaton.com 7
Table 8. Frame 3
Notes
1
Factory recommended spare parts.
2
575V available in 2015.
Table 9. Frame 4
Notes
1
Factory recommended spare parts.
2
575V available in 2015.
Catalog Number Catalog Number Catalog Number
Description 230V 480V 575V
Standard keypad
1
DXG-KEY-LCD DXG-KEY-LCD DXG-KEY-LCD
Main control board
1
DXG-SPR-CTRLBOARD DXG-SPR-CTRLBOARD DXG-SPR-CTRLBOARD
Control board cover DXG-SPR-BCOVER DXG-SPR-BCOVER DXG-SPR-BCOVER
Type 1/IP21 standard cover DXG-SPR-FR3CVR DXG-SPR-FR3CVR
2
Main fan kit
1
DXG-SPR-FR3FAN DXG-SPR-FR3FAN
2
Control fan DXG-SPR-FR34CF DXG-SPR-FR34CF
2
Bus capacitor DXG-SPR-FR3BC DXG-SPR-FR3BC
2
Main power board DXG-SPR-2FR3MPB DXG-SPR-4FR3MPB
2
EMI board DXG-SPR-2FR3EB DXG-SPR-4FR3EB
2
Drive board DXG-SPR-2FR3DB DXG-SPR-4FR3DB
2
Output board DXG-SPR-FR3OB DXG-SPR-FR3OB
2
Middle chassis cover DXG-SPR-FR3MCC DXG-SPR-FR3MCC
2
Outer housing DXG-SPR-FR3OH DXG-SPR-FR3OH
2
UL conduit plate DXG-SPR-FR3CPUL DXG-SPR-FR3CPUL
2
IEC conduit plate DXG-SPR-FR3CPIEC DXG-SPR-FR3CPIEC
2
Catalog Number Catalog Number Catalog Number
Description 230V 480V 575V
Standard keypad
1
DXG-KEY-LCD DXG-KEY-LCD DXG-KEY-LCD
Main control board
1
DXG-SPR-CTRLBOARD DXG-SPR-CTRLBOARD DXG-SPR-CTRLBOARD
Control board cover DXG-SPR-BCOVER DXG-SPR-BCOVER DXG-SPR-BCOVER
Type 1/IP21 standard cover DXG-SPR-FR4CVR DXG-SPR-FR4CVR
2
Main fan kit
1
DXG-SPR-FR4FAN DXG-SPR-FR4FAN
2
Control fan DXG-SPR-FR34CF DXG-SPR-FR34CF
2
Bus capacitor DXG-SPR-2FR4BC DXG-SPR-4FR24BC
2
Main power board DXG-SPR-2FR4MPB DXG-SPR-4FR4MPB
2
EMI board DXG-SPR-2FR4EB DXG-SPR-4FR4EB
2
Softstart board DXG-SPR-2FR4SB DXG-SPR-4FR4SB
2
IGBT module DXG-SPR-2FR4IGBT DXG-SPR-4FR4IGBT
2
Rectifier module DXG-SPR-2FR4RM DXG-SPR-4FR4RM
2
Brake chopper module DXG-SPR-2FR4BCM DXG-SPR-4FR4BCM
2
Middle chassis cover DXG-SPR-FR4MCC DXG-SPR-FR4MCC
2
Outer housing DXG-SPR-FR4OH DXG-SPR-FR4OH
2
UL conduit plate DXG-SPR-FR4CPUL DXG-SPR-FR4CPUL
2
IEC conduit plate DXG-SPR-FR4CPIEC DXG-SPR-FR4CPIEC
2
