Installation

Eaton Remote Power Panel (RPP) User’s Guide 164202125—Rev 5 www.eaton.com/powerquality 23

Figure 13. Wiring the Output Connections – Cooper Bussmann Panel (each side)

Top Entry Wiring

Bottom Entry Wiring

Output Ground

Branch Fuses and

Disconnect Switches

Current Transformers (CTs)

(one row each side)

Output Neutral
