Eaton Remote Power Panel (RPP) User’s Guide 164202125—Rev 5 www.eaton.com/powerquality 43
Chapter 7 Specifications
This section provides the following specifications for the Eaton Remote Power Panel (RPP):
l
Model number
l
Weights and dimensions
l
Electrical input and output
l
Meter
l
Environmental and safety
l
Surge Protective Device (SPD)
Table 15. Model Number
Model Feeds
Eaton RPP Up to four separate incoming feeds (450A, 900A)
Table 16. Weights and Dimensions
Dimensions (WxDxH)
Small RPP
Footprint Only: 610 x 610 x 2032 mm (24” x 24” x 80”)
Including One Door: 610 x 648.5 x 2032 mm (24” x 25.5” x 80”)
Including Two Doors: 610 x 684.5 x 2032 mm (24” x 27” x 80”)
Large RPP
Footprint Only: 610 x 992 x 2032 mm (24” x 39” x 80”)
Including One Door: 610 x 1031x 2032 mm (24” x 40.6” x 80”)
Including Two Doors: 610 x 1067x 2032 mm (24” x 42” x 80”)
Maximum Weight
Small RPP: 399 kg (880 lb)
Large RPP: 445kg (980 lb)
Note: Weights are approximate. Weight varies depending on installed options.
Table 17. Electrical Input
Nominal Input Voltage 208/120 Vac or 400/230 Vac three-phase, 4 wire + G
Input Voltage Range +10/-15%
Nominal Input Frequency 50/60 Hz
Input Frequency Range 45–65 Hz
Input Ratings 180A, 200A, 225A, 320A, 360A, 400A, 450A, 540A, 640A, 675A, 720A, 800A
Connections
Direct connection to panelboard circuit breakers or switch
Single and Dual Main Lug Options
Power terminals provide connection of up to a 200% rated neutral and a parity-sized insulated ground
Table 18. Electrical Output
Nominal Output Voltage 208/120 Vac or 400/230 Vac three-phase, 4 wire + G
Output Voltage Range +10/-15%
Nominal Output Frequency 50/60 Hz
Output Frequency Range 45–65 Hz
