User manual SEFELEC 5x Series 93 v1.06
Connect the SEFA-TE65 measurement power cord to in the HV socket provided; to lock the
cord push the plug until you hear a click. Proceed in the same way with the SEFA-CO175 return
cord on the socket connected to the earth.
IMPORTANT
The connectors are fitted with a thumb wheel at the back preventing
their extraction. Tighten the thumb wheel if necessary and loosen it to
disconnect the plug from the socket.
IMPORTANT
To disconnect the cords, make sure that there is no voltage and then
unscrew the rear thumb wheel, grasp the plug of the accessory by its
ribbed ring and pull to remove the plug from the socket.
SEFA-TE65
Guard connection
SEFA-CO175
