START-S1XL
Operating Guide
-7-
DIP 3-B OFF
DIP 4-B OFF
1° ch TX OPEN-STOP-OPEN-STOP...
2° ch TX CLOSE-STOP-CLOSE-STOP...
11 - 14 same as 1st ch TX
11 - 12 same as 2nd ch TX
11 - 13 photo-cell inverts when closing make a link when not use
11 - 15 make a link when not use
1° ch TX OPEN-STOP-OPEN-STOP...
2° ch TX CLOSE-STOP-CLOSE-STOP...
11 - 14 same as 1st ch TX
11 - 12 same as 2nd ch TX
11 - 13 photo-cell inverts when closing make a link when not use
11 - 15 make a link when not use
1° ch TX OPEN-STOP-CLOSE-STOP...
2° ch TX CLOSE-STOP-CLOSE-STOP...
11 - 14 same as 1st ch TX
11 - 12 ALT button NC make a link when not use
11 - 13 photo-cell inverts when closing make a link when not use
11 - 15 make a link when not use
1° ch TX OPEN-STOP-CLOSE-STOP...
2° ch TX CLOSE-STOP-CLOSE-STOP...
11 - 14 same as 1st ch TX
11 - 12 ALT button NC make a link when not use
11 - 13 photo-cell inverts when closing make a link when not use
11 - 15 make a link when not use
DIP A DIP B
ON
2
1
43
ON
2
1
43
ON
2
1
43
ON
2
1
43
ON
2
1
43
ON
2
1
43
ON
2
1
43
ON
2
1
43
A program: no automatic reclosing
D program: with automatic closing after pause time
B program: with automatic closing after pause time
C program: no automatic reclosing
DIP 3-B OFF
DIP 4-B ON
DIP A DIP B
DIP 3-B ON
DIP 4-B OFF
DIP A DIP B
DIP 3-B ON
DIP 4-B ON
DIP A DIP B
