4.3.1 Power wiring (Connector symbol: CN1, power supply)
WARNING
Be sure to perform grounding, otherwise an electric shock may be caused by electric leakage.
Use the wiring materials that correspond to the pump power.
Table 4.2 Wiring material
Type EV-A03-1 EV-A03-2 EV-A03-3
Applicable wire size AWG#12 (3.5 mm
2
) AWG#14 (2.0 mm
2
)
Number of wicks 3 4
