24
ALTERNATING CURRENT (AC) CONNECTION
WARNING
• Be sure any electric devices are turned o before plugging them in.
NOTICE
• Be sure all electric devices including the lines and plug
connections are in good condition before connection to the
generator.
• Be sure the total load is within the generator’s rated output.
• Be sure the receptacle load current is within receptacle rated
current.
• The generator (STATOR WINDING) is isolated from the AC
receptacle ground pin.
• Electrical devices that require a grounded receptacle pin
connection will not function if the receptacle ground pin is not
functional.
TIP: Make sure to ground the generator. When the electrical device is
grounded, the generator must also be grounded.
1. Start the engine.
2. Turn the ESC to “ON”.
3. Plug in to AC receptacle.
4. Make sure the AC pilot light is on.
5. Turn on any electric devices.
TIP: The ESC must be turned to “OFF” to increase engine speed
to rated rpm. If the generator is connected to multiple loads, please
remember to connect the one with the highest starting current rst and
connect the one with the lowest starting current last.
BATTERY CHARGING
TIP:
• The generator DC rated voltage is 12V.
• Start the engine rst, and then connect the generator to the battery
for charging.
• Before starting to charge the battery, make sure that the DC
protector is turned on.
1. Start the engine.
2. Connect the red battery charger lead to the positive (+) battery
terminal.
3. Connect the black battery charger lead to the negative (-) battery
terminal.
4. Turn the ESC “o” to start battery charging.
OPERATION
