EC-PM-80320 User's Manual
- 53 -
ESC $ Set absolute print position
Format: ASCII: ESC $ nL nH
Decimal: 27 36 nL nH
Hex: 1B 24 nL nH
Description:
Set the distance from the beginning of the line to the position at which subsequent characters are to be
printed.
The distance is (nL+nH*256)* (horizontal or vertical motion unit). Nl, nH=0~255.
Horizontal or vertical motion unit are specified by GS P command.
ESC % Selected/cancel user-define characters set
Format: ASCII: ESC % n
Decimal: 27 37 n
Hex: 1B 25 n
Description:
n=1, Select the user-define characters; n=0, Select inter characters.
Default: n=0
ESC & Define user-define characters
Format: ASCII: ESC & y c1 c2 [x1 d1..d(y*x1)] [xk d1..d(y*xk)]
Decimal: 27 38 y c1 c2 [x1 d1..d(y*x1)] [xk d1..d(y*xk)]
Hex: 1B 26 y c1 c2 [x1 d1..d(y*x1)] [xk d1..d(y*xk)]
Description:
Define the user-define Characters from c1 to c2.
y=3; 32≤c1≤c2≤126;
0≤x≤12; [Character A 12*24], 0≤x≤9; [Character B 8*16];
d=0~255; k=c2-c1+1;
y specifies the number of bytes in the vertical direction, x specifies the number of dots in the horizontal
direction, d specifies the user-define data.
ESC * Select bit-image mode
Format: ASCII: ESC * m n1 n2 d1..dk
Decimal: 27 42 m n1 n2 d1..dk
Hex: 1B 2A m n1 n2 d1..dk
Description:
Select the image mode with m; n1 and n2 specify the number of dots. The image data d1…dk
m=0,1,32,33; n1=0~255; n2=0~3; d=0~255.
k=n1+256×n2 (m=0, 1)
k= (n1+256×n2) × 3 (m=32, 33)
The number of dots in horizontal direction is n1+256×n2.
If the number dots exceed the max dot number in a line (shown as below), the excess data is ignored.
Vertical direction Horizontal direction
m Mode
Number of
dots
Dot
density
Dot
density
Number of dots
(max)
0
8-dot
single-density
8 68DPI 101DPI 288
1
8-dot
8 68DPI 203DPI 576
