Eclipse CD5425 User Manual

117
Mounting instruction
3) CD5425 + HDR105 + CH3083 + Power Amplifier
Caution Never connect the power supply to the speaker leads, otherwise it causes damage to the main unit.
TO POWER ANTENNA RELAY (supply)
TO HEAD LIGHT SWITCH (supply)
TO TURN ON LEAD OF EACH UNIT (supply)
TO ACC (Power supply)
1
TO BATTERY+12V (Permanent supply)
TO BATTERY+12V (Permanent supply)
2
TO GROUND
Brown
Brown/Black
Purple/Black (
-
)
Black
Purple (+)
Green/Black (
-
)
Blue/White
Orange/White
Blue Red
Yellow
Green (+)
Gray/Black (
-
)
White/Black (
-
)
White (+)
13P
13P
13P
16P
CD5425
2P
CH3083
HDR105
13P
2P
ANTENNA PLUG
ANTENNA EXTENSION CABLE
Gray (+)
3
4
5
6
TO STEERING REMOTE CONTROL
12
INTERCONNECTING CABLE
14
INSULATE EACH WIRE WITH TAPE
INSULATE EACH WIRE WITH TAPE
TO SIGNAL INPUT OF AUXILIARY POWER AMPLIFIER
NON-FADER
10
11
11
CD5425.book 117 ページ ２００４年１２月１１日 土曜日 午後５時９分
