118
Mounting instruction
4) CD5425 + CH3083 + 21010 + Power Amplifier
Caution
Never connect the power supply to the speaker leads, otherwise it causes damage to the main unit.
TO POWER ANTENNA RELAY (supply)
TO ACC (Power Supply)
1
TO BATTERY+12V
(Permanent supply)
2
TO GROUND
Brown
Brown/Black
Purple/Black
(
-
)
Black
Purple
(+)
Green/Black
(
-
)
Blue/White
Orange/White
Blue
Red
Yellow
Green
(+)
Gray/Black
(
-
)
White/Black
(
-
)
White
(+)
13P
16P
CD5425
21010
CH3083
13P
2P
ANTENNA PLUG
Gray
(+)
3
4
5
6
FRONT
8
9
REAR
TO SIGNAL INPUT
OF AUXILIARY
POWER AMPLIFIER
INSULATE EACH
WIRE WITH TAPE
INSULATE EACH
WIRE WITH TAPE
INTERCONNECTING CABLE
14
NON-FADER
TO TURN ON LEAD OF EACH UNIT (supply)
11
11
TO STEERING REMOTE CONTROL
12
10
TO HEAD LIGHT SWITCH (supply)
CD5425.book 118 ページ ２００４年１２月１１日 土曜日 午後５時９分
To Next Page
