CD8051 + 5083 + 5083 + Power Amplifier
TO POWER ANTENNA RELAY (Supply)
TO HEADLIGHT SWITCH (Illumination)
TO TURN-ON LEAD OF EACH UNIT (Supply)
CELLULAR PHONE
(For mute)
NON-FADER
TO BATTERY + 12V
(Permanent Supply)
ANTENNA PLUG
INTERCONNECTING CABLE
TO ACC (Power Supply)
TO SIGNAL INPUT OF
AUXILIARY POWER
AMPLIFIER
2
)
1
2
CD8051
13P
2P
2P
13P
( A )
( B )
13P
13P
5083
5083
16P
TO GROUND
Note : 1. The switch on the back side of CD changer ( A ) must be set to the "L" position.
2. The switch on the back side of CD changer ( B ) must be set to the "H" position.
Yellow
Red
Blue
Orange/White
Blue/White
Pink
Black
3
4
5
6
11
1
0
DIGITAL OUT
13
12
12
MP3 unit
14
