Specifications
9696
Specifications
<GENERAL>
Power Supply 14.4 V DC (11-16 V)
Current Drain 2A MAX
Dimensions (W x H x D)
In-Dash Unit 7" x 2" x 6 - 1/8" (178 x 50 x 155 mm)
<FM TUNER>
Frequency Range 87.75~107.9 MHz (200 kHz step)
Usable Sensitivity 13 dBf
50dB Quieting Sensitivity 21 dBf
Frequency Response 30~15,000 Hz, 3 dB
Stereo Separation 38 dB
<AM TUNER>
Frequency Range 530~1,710 kHz (10 kHz step)
Usable Sensitivity 20 µV
<CD SECTION>
Frequency Response 20~20,000 Hz, 3 dB
Wow & Flutter Below measurable limits
Stereo Separation 73 dB
S/N Ratio (A-weighted) 96 dB
Dynamic Range 95 dB
Total Harmonic Distortion 0.03 %
<AUDIO AMPLIFIER>
Output Level/Impedance 8 V (0 dB CD) / 55Ω line-out
impedance
Tone Action Bass : 10 dB at 60Hz
Mid : 10 dB at 600 Hz
Treble : 10 dB at 10 kHz
Loudness +10 dB at 100 Hz/+6 dB at 10 kHz
