Ecobee EMS Si - CONFIGURING THE HVAC SETTINGS; Equipment

17
YN/C
W
O/B
GRCRHCY2R1+R1-R2+R2-
W2
AUX
EMS Si Thermostat
1-stage AC
C
24V
2-stage Boiler
C
W2
R
W1
Y1
R
C
Y2
G
Air Handler
Dual stage boiler with air handler and single stage cool
* Remove RH/RC factory jumper
C terminal to be connected to heating
transformer common
