4 Functional description
The Turbo SMART II dosing pumps are electrically motor-driven diaphragm dosing
pumps, suitable for use with non-contaminated, non-abrasive dispensing media, viscosity
of max. 1100 mPas.
NOTICE!
Only Ecolab products approved for this dosing system may be used.
No liability is accepted for the use of products other than those
approved!
An integrated stepper motor drives the pump.
The stepper motor is controlled by integrated electronics, which control the dosage
amount by means of variable rotational speed. Various dosage profiles and modes of
operation (intake and dosage stroke speeds) can be configured.
The Turbo SMART II is available in different versions:
Article no. Pump head Sealings Scope of delivery Suitable for
106052
PP
EPDM
EU, complete pump with accessories
- packaged
Alkaline products106053
EU, pump
- unpacked
106099
US, pump module
- packaged
106064
FKM
EU, complete pump with accessories
- packaged
Acid products106065
EU, pump
- unpacked
106098
US, pump module
- packaged
106074
PVDF
EU, complete pump with accessories
- packaged
Products
containing
peracetic acid
106096
US, pump module
- packaged
106097 EPDM
US, pump module
- packaged
Chlorinated
products
DANGER!
Danger of the pump starting automatically
The pump is controlled via the power supply.
The automatic start of the pump is started as soon as the power supply is
connected, without having to press a switch/button beforehand.
For safe handling of the pump, a safety switch must be connected on site
or connected via the emergency stop function of the higher-level control
unit.
Functional description
21 Rev. 5-06.2018
