25
pin-1 side of each ribbon cable is always marked
with a colored stripe on the cable.
3. Plug one of the connectors on the FDD cable into the
FDD connector (B). It doesn't matter which connector
on the cable you use. Ensure that the pin-1 side of the
cable is matched with the pin-1 side of the connector.
Refer to the previous note.
4. Plug a power cable from the case power supply into
the power connector on the FDD (C).
When you first start up your system, go immediately to the
Setup Utility and use the Standard page to configure the
floppy diskette drives that you have installed. See Chapter 3
for more information.
Installing Add-on Cards
This mainboard has five 32-bit PCI (Peripheral Components
Interconnect) expansion slots, one 4xAGP slot, and one
Communications and Networking Riser (CNR) slot.
PCI Slots PCI slots are used to install expansion
cards that have the 32-bit PCI interface.
4xAGP Slot The 4xAGP slot is used to install a graph-
ics adapter that supports the 4xAGP
specification and has a 4xAGP edge con-
nector.
CNR Slot This slot is used to insert CNR cards with
Modem and Audio functionality.
Note: Before installing an add-on card, check the docu-
mentation for the card carefully. If the card is not
Plug and Play, you may have to manually configure
the card before installation.
