SONOTRAX(2009) Series Ultrasonic Pocket Doppler User Manual
33
Figure 3-5 Placing the probe
CAUTION
Do not take out or place the probe when the
Doppler is on. Remember to take out the probe
before switching on the Doppler, and place the
probe after switching off the Doppler.
(3) Replacing the probe
Remove the old probe:
Switch off the Doppler; hold the main unit with one
hand and pinch the jacket of the mini USB socket.
Lift the jacket up slightly and pull it out with mild
force; take out the probe.
CAUTION
Do not pull the probe cable directly.
理邦保密文件
EDAN CONFIDENTIAL
