VE-H100B Veterinary Pulse Oximeter User Manual
- 27 -
sensor. Use only the cable permitted by EDAN.
The cable for connecting the oximeter and PC with the Oximeter
Viewer Data Management Software is also connected to this port.
Type BF applied part
Input/output connector
SIO definition:
PIN
Name
Description
1
RSGND
The RS232 GND
2
LED+
LED drive signal, IR Anode
3
LED-
LED drive signal, Red Anode
4
RXD
H100 RS232 RX
5
Detector Anode
Detector anode
6
Connection
Detector connection
7
AGND
Analog GND
8
TXD
H100 RS232 TX
9
Detector Cathode
Detector cathode
