VE-H100B Veterinary Pulse Oximeter User Manual
- 34 -
 If the POST is successfully finished, the oximeter
sounds a tone and enters the main interface.
If there is an error during the POST, the following error codes will
display on the screen:
Error code
Indication
Battery Low
Indicates error for low battery
Error 02
Indicates error for SpO
2
board
Error 03
Indicates error for main control board
3.2 Measurement State
3.2.1 Measurement Modes
There are two measurement modes which are waveform mode and
large numeric mode. By default, the configuration is waveform
mode.
Waveform Mode
In the normal measurement state, oximeter can measure arterial
oxygen saturation and pulse rate, display oxygen saturation level
and symbol (%SpO
2
) and PR on interface. Besides, it can also
display pulse bar graph and Plethysmogram.
