47
Pin
I/0
Signal
Description
H
Output
Alarm
Used to indicate that the probe is in the
air (for tube inspections) (open drain with
10 kΩ pull-up).
J
Relay
contact
Relay 2
Relay used for automatic acquisition
sequence control
K
Relay
contact
Relay 3
Relay used for automatic acquisition
sequence control
L
Relay
contact
Relay 1
Relay used for automatic acquisition
sequence control
M
TTL Input
CLKACQ
Receives signal to trigger acquisition with
probe position along the scanning axis
N
NC
No connection - Reserved
P
TTL Input
Φ B2
Phase B axis 2
R
TTL Input
Φ A3
Input 5
Phase A axis 3
User-defined input for automatic
acquisition sequence
S
Supply
Output
+5 V
T
TTL Input
Φ B3
Input 4
Phase B axis 3
User-defined input for automatic
acquisition sequence
U
TTL Input
Φ A3
Phase A axis 3
