Chapter 2
| Installation Overview
Switch Installation Tasks
– 21 –
As connections are made, check the port status LEDs to be sure the links are valid.
Go to the chapter “Port Connections”
Figure 8: Making a Connection to an RJ-45 Port
10/100/1000BASE-T RJ-45 Port.
Twisted-pair Cable with RJ-45 Plug.
To Next Page
