Chapter 1
| Access Point Overview
Key Technical Specifications
– 12 –
Key Technical Specifications
The following table contains key system specifications for the AP.
Table 1: Key Technical Specifications
Item Specification
Ports One 10/100/1000 Mbps RJ-45 port
Network Interface RJ-45 Port:
◆
1000BASE-T, PoE (PD)
Console Port RS-232, RJ-45 connector
2.4 GHz Radio IEEE 802.11b/g/n
5 GHz Radio IEEE 802.11a/n
Internal Antennas 2x2 MIMO omni antennas for 2.4 GHz and 5 GHz
Antenna Gain 3 dBi @ 2.4 GHz
4 dBi @ 5 GHz
Radio Frequencies 2400 ~ 2483.5 MHz
2412 ~ 2472 MHz
5745 ~ 5825 MHz (China)
5180 ~ 5320 MHz (ETSI)
5500 ~ 5700 MHz (ETSI)
LEDs Power, Network
PoE Input Power 48 VDC, 0.3A
AC Power Adapter AC Input: 100 ~ 240 VAC
DC Output: 12 VDC, 2 A
Power Consumption 22.5 W maximum
Weight 500 g (1.10 lbs)
Size (W x D x H): 140 x 140 x 47.8 mm (5.51 x 5.51 x 1.88 inches)
Temperature Operating: 0 °C to 40 °C (32 °F to 104 °F)
Storage: -20 °C to 70 °C (-4 °F to 158 °F)
Humidity Operating: 5% to 95% (non-condensing)
