Understanding the Network Status LED
– 28 –
Understanding the Network Status LED
The AP includes an LED indicator to indicate network link status and activity. The
LED is shown below and is described in the following table.
Figure 13: Network Status LED
How to Connect to Radio Interfaces
The 802.11b/g standard operates in the 2.4 GHz band and the 802.11a standard in
the 5 GHz band. The 802.11n standard operates in both the 2.4 GHz and 5 GHz
bands. Note that 802.11n is backward compatible with 802.11a, b, and g.
Once the AP is installed and powered on, wireless clients can connect to the
802.11b/g/n radio interface using the 2.4 GHz band and to the 802.11a/n radio
interface using the 5 GHz band. The radio and authentication settings for wireless
clients can be configured through management interfaces on the wireless access
Network Link/Activity
Table 3: Network Status LED
LED Condition Status
Network Link/
Activity
On Amber The 2.4 GHz, 5 GHz, or LAN interface has a valid link.
Flashing Amber Flashing indicates network activity.
Off The device is powered off.
