UNLESS AS MAY BE OTHERWISE PROVIDED BY CONTRACT, THESE DRAWINGS AND SPECIFICATIONS ARE THE PROPERTY
OF "EDGETECH" AND ARE ISSUED IN STRICT CONFIDENCE AND SHALL NOT BE REPRODUCED, COPIED OR USED AS THE
BASIS FOR THE MANUFACTURE OR SALE OF APPARATUS WITHOUT PERMISSION. COPYRIGHT @ 2012 EDGETECH INC.
10
REV
REVISIONS
DESCRIPTION DATE APPROVED
Initial ReleaseA 12/3/12 BS
ASSY SUB CABLE 2205 AUV SBP RX
03 POS MALE TO J562
DRAWING NO.
TBD
REV
B
SCALE
CARDFILE NAME
12/3/2012
DATE
page 1 of 1
0012112
DRAWN: BS
APPROVALS
CHECKED:
ENG:
ISSUED
SYSTEM
MCBH3M
2
4
GND
J562 SIM
Notes:
1 - Cable length 6"
2 – Heat shrink all solder connections
3 – Splice must be with in 1" of bulkhead
4 - Cover cable ends with heat shrink
5 - Ferrite must have 3 turns of wire through the center
6 - Install ferrite and connectors after bulkhead is installed on End cap
1
3
5
·
6
1
2
3
-RX
+RX
4 Little Brook Road
W.Wareham, MA 02576
Tel: (508) 291-0057 / Fax: 291-2491
MCBH3M
Male Face View
1
3
2
+RX -RX
GND
1 2
6
·
< 2"
20 30
50
40
L1
3 Turns In
Top View
ECR
Convert cable to CoonerB 7/8/14 PO2687
