32.00±.020
812.80±0.508
8.50±.020
215.90±0.508
12.00
304.80
SUGGESTEED CLEARANCE
FOR CABLE BEND RADII
CONNECTOR ORIENTATION IS FOR
DEMONSTRATION ONLY
AND DOES NOT REFLECT THE
ACTUAL LAYOUT OF THE
DELIEVERED END CAP
NOTES:
MATERIAL: ALUMINUM 6061-T6 HARDCOAT ANODIZED
DEPTH RATING: 3000M
*WEIGHT IN WATER: 17.6 LBS [7.9 KG]
*WEIGHT IN AIR: 85.0 LBS [38.6 KG]
DIMENSIONS IN [BRACKETS] ARE IN MM
*ALL WEIGHTS ARE ESTIMATED UNTIL FIRST RENDERING IS COMPLETE
SEE NOTES
SEE NOTES
DIMENSIONS ARE IN INCHES
INTERPRET DIM AND TOL PER
ASME Y14.5-1994
THIRD ANGLE PROJECTION
2019 EDGEONE LLC.
WEST WAREHAM, MA 02576
4 LITTLE BROOK ROAD
TEL. (508)291-0057
WWW.EDGETECH.COM
+/-0.5°
+/-1/64+/-.005+/-.010
IN ANY WAY WITHOUT THE EXPRESS WRITTEN PERMISSION OF EDGEONE LLC.
ORE) AND ARE ISSUED IN STRICT CONFIDENCE. THEY SHALL NOT BE REPRODUCED, COPIED OR USED
THESE DRAWINGS AND SPECIFICATIONS ARE THE PROPERTY OF EDGEONE LLC DBA EDGETECH (OR
D
F
DATE
DESCRIPTION
REVISIONS
APPROVED
E
D
2
REV
ECR#
3
C
B
A
REV
1
CADFILENAME:
SCALE
TITLE
DRAWING NO.
SHEET 1 OF 1
2
ANGLES
3 PLACES
FRACTIONS
TOLERANCES
MECH
DRAWN
CHECKED
ELECT
SYSTEM
APPROVALS
REMOVE BURRS, BREAK SHARP EDGES
MATERIAL
2 PLACES
FINISH
3
DECIMALS
DO NOT SCALE PRINT
UNLESS OTHERWISE NOTED:
456
F
E
D
45
C
B
6
A
1 PLACE
+/-.050
1
A RELEASED TO PRODUCTION 6/03/19 MLB
BERRYMAN
STRITTMATTER
6/3/19
6/3/19
DOC DRAWING ICD 2205 230/540/850 4xSB
ELECTRONICS BOTTLE
0022244
A
0021987.SLDASM
1:2
