EDGETECH PART NO.: 0022320
SUBCONN CONNECTOR
WETMATE MCIL3F
SUBCONN CONNECTOR
LOCKING SLEEVE MCDLSF
10X
.28in
7.1mm
THRU ALL
0in
0mm
3X
.5in
12.7mm
2X
14.5in
368.3mm
3X
28.5in
723.9mm
29.0in
736.6mm
30.0in
762mm
0in
0mm
3X
.5in
12.7mm
5.0in
127mm
3X
19.5in
495.3mm
20.0in
508mm
7.5in
190.5mm
21.5in
546.1mm
4X
10.0in
254mm
.5in
12.7mm
24.0±.5
609.6±12.7
POLARITY MARK
URETHANE
& RUBBER
STRITTMATTER 11/7/19
0022320.SLDASM
1:2
0022774
A
ICD, HYDROPHONE, PVDF, FLAT 20 INCH 29 INCH,
W/ 03 POS CONN, 24 INCH PIGTAIL
NOTES:
WEIGHTS:
1.
IN AIR: 16.4 LBS. [1.8KG]
IN WATER: 5.6 LBS. [2.5KG]
DEPTH RATINGS:
2.
THE SENSOR MATERIAL IN THIS HYDROPHONE HAS A DEPTH THRESHOLD LIMIT.
EXPOSURE BEYOND THIS THRESHOLD RESULTS IN A ONE TIME (PERMANENT)
MATERIAL SENSITIVITY LOSS.
THRESHOLD DEPTH: 670m
-1.0dB SENSITIVITY LOSS DEPTH: 1340m
-2.5dB SENSITIVITY LOSS DEPTH : 2040m
SENSITIVITY LOSS DATA BEYOND 2040 METERS IS NOT CURRENTLY KNOWN.
HOWEVER, CONSTRUCTION OF THE HYDROPHONE MAKES IT CAPABLE OF
DEPTHS TO 6000 METERS.
STRITTMATTER 11/7/19
PES
11/07/19
RELEASED TO MANUFACTURING
A
DIMENSIONS ARE IN INCHES
INTERPRET DIM AND TOL PER
ASME Y14.5-1994
THIRD ANGLE PROJECTION
2019 EDGEONE LLC.
WEST WAREHAM, MA 02576
4 LITTLE BROOK ROAD
TEL. (508)291-0057
WWW.EDGETECH.COM
+/-0.5°
+/-1/64+/-.005+/-.010
IN ANY WAY WITHOUT THE EXPRESS WRITTEN PERMISSION OF EDGEONE LLC.
ORE) AND ARE ISSUED IN STRICT CONFIDENCE. THEY SHALL NOT BE REPRODUCED, COPIED OR USED
THESE DRAWINGS AND SPECIFICATIONS ARE THE PROPERTY OF EDGEONE LLC DBA EDGETECH (OR
D
F
DATE
DESCRIPTION
REVISIONS
APPROVED
E
D
2
REV
ECR#
3
C
B
A
REV
1
CADFILENAME:
SCALE
TITLE
DRAWING NO.
SHEET 1 OF 1
2
ANGLES
3 PLACES
FRACTIONS
TOLERANCES
MECH
DRAWN
CHECKED
ELECT
SYSTEM
APPROVALS
REMOVE BURRS, BREAK SHARP EDGES
MATERIAL
2 PLACES
FINISH
3
DECIMALS
DO NOT SCALE PRINT
UNLESS OTHERWISE NOTED:
456
F
E
D
45
C
B
6
A
1 PLACE
+/-.050
