3-8 Diagnostic
Click Diagnostic in the menu to open the sub-menu which contains 4 items: Ping, ATM
Loopback, ADSL and Diagnostic.
3-8-1 Ping
Click Ping in the sub-menu to open the screen of Fig 3.8.1.
Fig 3.8.1
Label
Description
Host Address
Enter the IP Address here.
Go!
Click this button to begin to Ping the Host Address.
