Edimax AR-7211A - CHAPTER II: HARDWARE SETUP

8
Rear Panel
Item
Usage
Line
Line RJ-11 port
Reset
Resets device to factory defaults
(to restore factory defaults, push a paper clip into the hole
when the device is powered and hold for over 5 seconds)
Ethernet
Ethernet RJ-45 port
Power ON/OFF
PWR
Power connector
(connects to DC12V 500mA power adapter)
USB
Connects to computer via USB cable
(USB driver installation required. See APPENDIX A for details.)
1-4 System Requirements
First, make sure that you have prepared these following items to guarantee the router
can work properly.
 Service subscription
 An 10BaseT/100BaseT Ethernet card installed on your PC
 HUB or Switch (attached to several PCs through one of Ethernet interfaces on the
device)
 Operating system: Windows 98SE, Windows 2000, Windows ME, or Windows XP
 Internet Explorer V5.0 or higher, or Netscape V4.0 or higher, or Firefox 1.5 or
higher
