Service, spares and accessories
7.3.2 Spares common to all Diffstak pumps
7.3.3 Spares for Diffstak M- and P-model pumps
Spare Pump model
63/150 100/300 160/700* 250/2000*
Heater: 100 to 125 V H017-00-182 H017-00-199 H017-00-102 H017-00-140
(0.45 kW) (0.65 kW) (0.35 kW) (0.85 kW)
H017-00-059 H017-00-161
(1.0 kW) (1.4 kW)
Heater: 210 to 225 V H017-00-186 H017-00-097 H017-00-107 H017-00-134
(0.45 kW) (0.65 kW) (0.35 kW) (0.85 kW)
H017-00-63 H017-00-155
(1.0 kW) (1.4 kW)
Heater: 230 to 250 V H017-00-191 H017-00-190 H017-00-113 H017-00-137
(0.45 kW) (0.65 kW) (0.35 kW) (0.85 kW)
H017-00-54 H017-00-158
(1.0 kW) (1.4 kW)
Backing ‘O’ ring assembly (fluoroelastomer) C105-11-395 C105-14-395 C105-14-395 C105-16-395
Drain and filler-plug ‘O’ rings
VIT 0056-24 (pack of 5)
H021-23-027 H021-23-027 H021-23-027 H021-23-027
Spare Pump model
63/150 100/300 160/700 250/2000
Valve-plate ‘O’ ring H021-06-050 H021-06-061 H021-02-221 H021-06-093
VIT 0335 VIT 0346 VIT 1221 VIT 0449
Valve shaft seal ‘O’ ring H021-06-010 H021-06-010 H021-06-011 H021-06-121
VIT 0012
▲
VIT 0012
▲
VIT 0111
▲
VIT 1121✝
Valve blanking plate ‘O’ ring H021-06-010 H021-06-010 H021-06-011 H021-06-128
VIT 0012
▲
VIT 0012
▲
VIT 0111
▲
VIT 1128✝
Position indicator spares kit◆ B344-32-023 B344-32-023 B344-32-023 B3 44-32-023
* One heater of each power rating is required for the 160/700 and 250/2000 Diffstak pumps.
▲ Pack of 5
✝ Pack of 2
◆ P-model pumps only
